Retro LED Deck Light

Retro LED Deck Light

SKU: LGJJXA10N100F30

The LED vapor tight jelly jar retrofit kit will mount easily to many existing “Jelly-Jar” fixtures that have Glass Globes and Protection Cages. Simply remove the Cage, Globe and Bulb. Then unscrew the portion of the fixture that the A-19 receptor is mounted to and disconnect the wiring. Place the new gasket between the old fixture and the new LGS Luminary, connect the wiring, and screw in the 4 screws into the new LGS Luminary to the existing fixture. It’s that simple! LGS Marine's Jelly Jar Lamps are designed for harsh environments in both wet and dry locations, outdoor led lighting, or indoor led lighting. Made of die cast aluminum, they are available in Wall Mount, Ceiling Mount, and a retrofit kit. They are IP66 rated with a built-in junction box that has four knockouts to accommodate 3/4” conduit. There is no glass jelly-jars, or globe cage to vibrate loose or break. The 10W LED fixture projects a 90-degree beam in a warm 3000K light, emitting up to 1000 lumens.





LED DECK LIGHT BROCHURE



KEY FEATURES

  • Lens can be Clear-Frost, or Tea-Yellow.
  • Viable in saltwater or fresh water.
  • Resilient in hash conditions like vibrations, jolts, shock, and inclement weather.
  • Easy installation. Comes with a gasket to go between the bulkhead and fixture.
  • IP65 Rated.
  • 5-year factory warranty.



PRODUCT SPECIFICATIONS

LED package: SMD 3030
Power consumption: 10W+-5%
Input voltage: 100~277V AC 50/60Hz
Efficacy: Up to 100 lm/W
THD: <15%
PF: >0.98
CRI: >70
Dimming: No
Material: Aluminum
Beam Angle: 90º
Fire rating: UL94V0
IP rating: IP66
Operating temperature: -40ºC~50ºC

Available Now!
Lens Finish: Frosted
